The machine applies to slit cellophane, PET, OPP, CPP, PE, PS, PVC and computer security labels, electronic computers, optical materials, film roll, aluminum foil roll, all kinds of paper rolls, film and printing of various materials.,etc
| TECHNICAL SPECIFICATIONS |
AS-1000 |
| Slitting Speed |
10-400m/min |
| Jumbo Roll Width |
1000mm |
| Min. Width of Produce |
50mm |
| Inner Diameter of Paper Core | 3'' or 76mm（optional: 6'' or 152mm） |
| Max. Unwinding Diameter |
800mm |
| Max. Rewinding Diameter |
600mm |
| Tolerance of EPC |
≤0.1mm |
| Voltage |
AC380V |
| Total Power |
12KW |
| Dimensions |
2300×4000×1900mm |
| Machine Weight |
4000KGS |
